CORTADObin

CORTADObin is a very advanced and sophisticated ARM system board designed and manufactured by GTI (Globalscale Technologies, Inc.) which is based on MediaTek Genio 510 IoT Application Processor (MT8370) designed for various Artificial Intelligence (AI) and Internet of Things (IoT) use cases requiring high-performance edge processing, advanced multimedia, and connectivity capabilities, multiple high-resolution cameras, connected touchscreen displays, and the use of a multi-tasking High-Level Operating System (HLOS). The highly-capable octa-core application processor utilizes the Arm® DynamIQ™ technology by combining high-performance Cortex-A78 and power-efficient Cortex-A55 cores equipped with Arm Neon™ engine.

CORTADObin offers the necessary processing power to support OpenOS, along with demanding applications such as web browsing, email, and games. Content can be enhanced by the 2D/3D graphics accelerator (Arm Mali-G57 MC2 GPU) and then visualized on a high-resolution touchscreen display. To provide advanced multimedia applications and services such as streaming audio and video, the device features multi-standard video encoder and decoder engines, and an advanced audio subsystem.

The AI Processor Unit (APU) enables deep learning, Neural Network (NN) acceleration, and Computer Vision (CV) applications. The latter, combined with up to a 32MP camera, can clearly and accurately perform AI-vision functions such as facial recognition, object identification, scene analysis, optical character recognition, and much more. An extensive set of interfaces, connectivity, flexible storage, and memory options further enhance the capabilities of the CORTADObin and give application designers the freedom to customize.

SoC
Dual-core Arm® Cortex®-A78 processor
Plus
Quad-core Arm Cortex-A55 processor

Memory
8GB DDR4
64GB onboard eMMC

Ethernet
1x 1Gb RJ45
1x 2.5Gb RJ45

Wireless
1x Wi-Fi 802.11 a/b/g/n/ac/ax 2T/2R
1x Low Power 2.4Ghz

USB Ports
1x USB 2.0 Type A
1x Micro USB OTG
1x USB 3.0 Type A
1x USB 3.0 Type C

UART
1x Micro USB
1x DB-9

AV
1x 1200*1920 7″ LCM touch panel
2x 2W+2W stereo speaker
1x Stereo speakerphone jack
1x Stereo digital microphone jack

Expansion ports
1x M.2 key A/E
1x M.2 key B
2x Nano SIM socket (connected to M.2 key B)
1x 36-pin Raspberry Pi connector
1x CAN BUS connector

Others
1x Micro SD card slot
